LJZ2-G500 2 head Aluminum Cutting Saw Machine with ce

Price:	15000.0~20000.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU,
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: G500

Production Capacity: 100sets/month at least

Delivery Date: 1 month

Means of Transport: Ocean,Land,Air,

Packing: wooden box,steel box

cutting width: max.135mm

LJZ2-G500 2 head Aluminum Cutting Saw Machine with ce:cutting lenghth 400-4200mm
cutting width max.135mm
cutting angle 90/45

LJZ2-G500 2 head Aluminum Cutting Saw Machine with ce :

Performance features:

1. The body adopts reinforced structural steel design to ensure good rigidity, difficult in deformation after the aging treatment

2.Large in machining range, used in cutting and blanking of aluminum profiles and curtain wall profiles

3. High in machining efficiency; suitable for scaled production

4. CNC technology is adopted mated with Germany Siemens motor to realize auto sizing blanking

5. High quality aluminum product dedicated hard alloy saw blade to ensure cutting precision

6. The saw blade feeding system adopts air-hydraulic buffering cylinder to ensure uniform feeding and even movement

7. The feeding mechanism adopts imported flat way and linear bearing pair, high in movement precision and accurate in positioning

LJZ2-G500 2 head Aluminum Cutting Saw Machine with ce

advantages:

1.The mechanical head realizes auto swivel and bilateral positioning and clamping, accurate and stable

2. Dedicated subsection and arcus difference compensation function to ensure precise blanking

3. Dedicated full-auto corner saw function

4. The circuit system is equipped with motor phase sequence protector to increase the system safety.

LJZ2-G500 2 head Aluminum Cutting Saw Machine with ce :

Technical parameters:

Power supply------------------------------------------------------- 380 50HZ
Power of motor------------------------------------------------------ 2×2.2KW+1.5KW

Speed: ------------------------------------------------------- 2800/MIN

Air source pressure --------------------------------------------- 0.5-0.8MPA
Air consumption ---------------------------------------------------- 60L/MIN

Cutting length: ------------------------------------------------------- 400-4200MM

Cutting width: ------------------------------------------------------- Max.135MM

Cutting heigt: ------------------------------------------------------- Max.300MM

Cutting angle: ------------------------------------------------------- 90\45

Feedrate: ------------------------------------------------------- Stepless speed 0-3M/MIN

LJZ2-G500 2 head Aluminum Cutting Saw Machine with ce

real pictures:
