Middle grade precision NC four-position double-side cut seamless welding of plastic doors and windows

Price: 15000.0~20000.0 USD
Payment Terms: T/T,L/C,D/A,D/P,WU,
Place of Origin: Shandong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: SHZ4-WF2-M
Production Capacity: 100sets.month
Delivery Date: 1 month
Means of Transport: Ocean,Land,
Packing: wooden box,steel box
Welding height: 20-120MM

Middle grade precision NC four-position double-side cut seamless welding of plastic doors and windows;Welding width Max.120MM


Middle grade precision NC four-position double-side cut seamless welding of plastic doors and windows
Performance features:

1.Specially suitable for the production of high grade colorful doors and windows

2.True color touch screen and high precision round guide linear motion pair are adopted, high in part machining precision, strict in assembly quality control and good in stability

3.The framework is welded by high quality all-steel square tube, high in strength without deformation

4.Automatically clear the welding splatter with no white edge to upgrade doors and windows
5.Unique cutting blade design, good in cutting effect without dull tackle

6.Patented optimization of control and pneumatic system greatly enhance the weld strength

7.Good in stability, smooth and elegant in finished products of doors and windows

8.Originated technology all over the country, settle the problem of big and small surface thoroughly

9.Various high grade co-extruded, embossing, overlay film, steel-plastic compound profiles are weldable

Middle grade precision NC four-position double-side cut seamless welding of plastic doors and windows
Technical parameters:

Voltage                 220V 50HZ
Total Power             4.7KW
Air consumption         150L/MIN
Welding height          20-120MM
Welding width          Max.120MM
Welding into window size 400-4300MM
Outside dimension       5300×900×1500MM
Weight                1700KG

Middle grade precision NC four-position double-side cut seamless welding of plastic doors and windows

real picuture:
Middle grade precision NC four-position double-side cut seamless welding of plastic doors and windows
bigPhoto
